Blue water vending cabinet
- 875 × 900 × 1920 mm, freestanding
- Two amount displays + contactless readers
- One glazed filling compartment
Step 1 · Choose a cabinet
Compare the five vending cabinets
Every cabinet is built in our factory and configured per order: power, frequency, payment modules, 4G and branding. The choice comes down to format, filling points and how customers use the site.
| Cabinet | Format | Filling points | Controls | Size |
|---|---|---|---|---|
| Blue water vending cabinet | Freestanding | One glazed filling compartment | Two amount displays, contactless readers | 875 × 900 × 1920 mm |
| Water-drop water vending cabinet | Freestanding | One filling door | Card reader, coin and banknote slots | 875 × 900 × 1920 mm (reference, customizable) |
| Wheeled water vending cabinet | Freestanding on castors | One glazed filling door | Numeric keypad, status display | 875 × 900 × 1920 mm (reference, customizable) |
| Blue-canopy double-door vending cabinet | Freestanding with blue canopy | Two glazed filling doors | Two front control sets | 875 × 900 × 1920 mm (reference, customizable) |
| Metal-canopy water vending cabinet | Freestanding on castors with stainless-steel canopy | One glazed filling door | Single front control panel | 875 × 900 × 1920 mm (reference, customizable) |
Sizes: the blue cabinet is measured at 875 × 900 × 1920 mm. Other cabinets show this standard size as a reference — every cabinet can be built to a different size, confirmed in the drawing for your order.
Water-drop water vending cabinet
- Coin, banknote and card slots
- Start / ozone / stop controls
- Single filling door
Wheeled water vending cabinet
- Base on castors
- Numeric keypad + status display
- Coin, note and contactless payment
Blue-canopy double-door vending cabinet
- Two glazed filling doors
- Two front control sets
- Blue overhead canopy
Metal-canopy water vending cabinet
- Stainless-steel canopy
- On castors
- Single glazed filling door
Step 2 · Check your site
Six things to check before you order
Send these with your inquiry and we can confirm the configuration and quote in one round.
Site & installationIndoor or outdoor, floor space, customer approach and service access. The final drawing confirms clearances and fixing points.
Water sourceMains, borehole or tanker water. Share a water analysis so the treatment stages, or a separate RO system, can be specified.
Power supply110, 220, 230 or 240 V AC at 50 or 60 Hz. Tell us your local supply and we build the cabinet for it.
Payment & containersCoin, banknote, IC card or credit card, matched to your currency. Include the container sizes customers bring.
Branding & connectivityYour logo and cabinet graphics, plus optional 4G LTE configured for your destination network.
Destination & importYour country and port decide the documents and any pre-shipment inspection, such as PVoC or SONCAP.
Step 3 · Water treatment
Do you need a separate RO system?
Each vending cabinet carries its own filtration and disinfection stages, confirmed for your feed water. Add the stainless-steel RO system when you need more daily output than the cabinet produces, supply several filling points from one plant, or your water needs heavier pretreatment.
TreatmentSand · carbon · softener · RO
Power220 V / 380 V AC
Step 4 · Plan the specification
Specification starting points
- Electrical supply
- Vending cabinets: 110 / 220 / 230 / 240 V AC, 50 or 60 Hz
Choose the voltage and frequency for your destination. The RO system is quoted with 220 V or 380 V AC.
- Dimensions
- Standard cabinet: 875 × 900 × 1920 mm
Measured on the blue cabinet, packed at 980 × 1000 × 2050 mm. Use it as a reference for the other cabinets; size and capacity are customizable and confirmed in your order drawing.
- Filling speed
- Give a target in L/min
Tell us the container volume and the filling time you want. Dispensing flow is separate from treatment output; a storage tank can support faster filling for a limited time.
- RO production
- Give your daily output
Share the daily volume, operating hours, feed-water analysis and product-water target. The quotation confirms the system configuration and expected performance.
- Communication
- Optional 4G LTE
Configured for your destination network. Mention it when you describe the configuration.
Next: how to order — quotation, proforma invoice, deposit, production and FOB Ningbo shipping. Or read what a water vending machine costs.
