Cabinet view cropped from the supplied product sheet.
Water-drop water vending cabinet
A light-blue self-service water vending cabinet with an illuminated water-drop header, card-reader interface, coin and banknote slots and a single filling door.
- Format
- Freestanding
- Filling points
- One filling door
- Reference size
- 875 × 900 × 1920 mm (reference, customizable)
- Connectivity
- 4G LTE (optional)
Overview
A light-blue self-service water vending cabinet with an illuminated water-drop header, card-reader interface, coin and banknote slots and a single filling door. The cabinet graphics show a treatment chain from sand and carbon filtration through precision filtration, RO, mineral treatment, UV and ozone.
6-stage treatment
- 1Sand & carbon
- 2Precision filter
- 3Reverse osmosis
- 4Mineral
- 5UV
- 6Ozone
Sand, carbon, precision filtration, RO, mineral, UV and ozone stages are shown on the cabinet. Confirm the final stage configuration for your feed water.
Specifications
- Power supply
- 110 V / 220 V / 230 V / 240 V AC — selectable, customizable
- Frequency
- 50 Hz or 60 Hz
- Payment options
- Coin / banknote / IC card / credit card — optional configurations
- Display & controls
- Illuminated 24-hour header, card-reader interface, coin and banknote slots, and START / OZONE / STOP controls
- Connectivity
- 4G LTE — optional, configured for your destination network
- Cabinet format
- Freestanding
- Filling points
- One filling door
- Configuration
- Power supply, frequency, payment modules and optional 4G LTE are selected for each order. Customized for your market.
- Reference dimensions
- 875 × 900 × 1920 mm (standard cabinet, for reference)
- Dimensions & capacity
- Customizable; the reference size is our standard cabinet, and final dimensions and capacity are confirmed with your order
- Photograph shows one representative cabinet. Final panel graphics, payment modules and treatment stages are confirmed for each order.
- Select the voltage and frequency for your destination when ordering.
- Payment terminals are matched to the destination currency and network; confirm the final module set and terminal type in the quotation.
Customization
110, 220, 230 or 240 V AC at 50 or 60 Hz — built for your country’s grid.
Any combination of coin, banknote, IC card and credit card, with terminals matched to your currency and network.
Optional module configured for your destination network.
Your brand, colours and front-panel layout — discussed for each order.
Shipping & Payment
- Samples & minimum order
- Single-unit and small sample orders are welcome. Minimum order quantities depend on the model and level of customization.
- Payment terms
- A deposit is paid to place the order, with the balance paid before shipment. The payment method and deposit amount are agreed for each order.
- Shipping & trade terms
- Sea freight can be quoted FOB Ningbo. Other trade terms and shipping arrangements can be discussed for your destination.
- Production & lead time
- Lead time depends on the configuration and order quantity. The agreed production and dispatch schedule is confirmed in the proforma invoice.
- Warranty & consumables
- Warranty duration, coverage and support terms are agreed with your order. Filter cartridges and other consumables are excluded from warranty coverage.
- Installation & equipment support
- Local installation and utility connections are arranged by the buyer. Available instructions, equipment documents and technical support are confirmed for your order.
